RØDECaster Sync allows a RØDECaster Video Core to integrate with a RØDECaster Pro II or RØDECaster Duo, creating a unified audio and video production system. When connected, both devices share control and audio routing, giving you expanded inputs, outputs, and hands-on mixing.
Follow the steps below to set up RØDECaster Sync.
Before You Begin
- Ensure both devices are powered on
- Update both units to the latest firmware from the RØDECaster App
RØDECaster App: You can download the latest RØDECaster App from here.
- Have a USB-C cable ready
Connecting the Devices
- Connect one end of a USB-C cable to USB 4 or USB 5 on the RØDECaster Video Core.
- Connect the other end of the cable to USB 1 on the RØDECaster Pro II or RØDECaster Duo.
- When the connection is detected, a prompt will appear on the RØDECaster Pro II / Duo display asking if you want to enter Sync Mode.
- Confirm the prompt to enable RØDECaster Sync.
Manually Entering or Exiting Sync Mode
You can manually enable or disable Sync Mode at any time from the RØDECaster Pro II or RØDECaster Duo.
- Open Settings
- Select Operation Mode
- Choose Sync Mode
For more information on RØDECaster Video Core, please see our RØDECaster Video Core User Guide.
